Obtain the complete inventory and price list of steel sheet piles
Steel Sheet Pile Supplier in China | U & Z Type Sheet Piles for Construction
High strength for deep foundation projects
Excellent interlock system for water tightness
Suitable for temporary and permanent structures
Reusable, reducing overall project cost
Available in hot rolled and cold formed types
| Model | Effective Width (mm) | Section Height (mm) | Web Thickness (mm) | Flange Thickness (mm) | Unit Weight (kg/m) |
| Z260 | 400 | 260 | 6 | 6 | 22.5 |
| Z300 | 400 | 300 | 7 | 7 | 26.8 |
| Z360 | 400 | 360 | 8 | 8 | 31.2 |
| Z400 | 400 | 400 | 8 | 8 | 34.5 |
| Z500 | 500 | 500 | 9 | 9 | 42.6 |
| Z600 | 600 | 600 | 10 | 10 | 51.8 |
| Type | Width (mm) | Height (mm) | Thickness (mm) | Section Area (cm²/m) | Weight (kg/m) | Moment of Inertia (cm⁴/m) |
| U400 | 400 | 125–130 | 8–12 | 75–110 | 58–86 | 1,500–2,800 |
| U500 | 500 | 130–135 | 8–13 | 90–130 | 70–102 | 2,500–4,500 |
| U600 | 600 | 140–150 | 9–14 | 110–160 | 85–125 | 4,000–7,500 |
| U700 | 700 | 150–160 | 10–15 | 130–190 | 100–145 | 6,500–11,000 |
| U750 | 750 | 155–165 | 10–16 | 140–210 | 110–160 | 8,000–13,500 |
Click the button on the right to contact us
Applications of Steel Sheet Piling
Retaining wall systems
Cofferdam construction
Marine & port engineering
Flood control and riverbank protection
Underground basement construction
Note:
1.Free sampling, 100% after-sales quality assurance, Support any payment method;
2.All other specifications of round carbon steel pipes are available according to your requirement (OEM&ODM)! Factory price you will get from ROYAL GROUP.
Packaging is generally naked, steel wire binding, very strong.
If you have special requirements, you can use rust proof packaging, and more beautiful.
Transportation: Express (Sample Delivery), Air, Rail, Land, Sea shipping (FCL or LCL or Bulk)
Q: What is the difference between U type and Z type sheet pile?
A: U type is widely used for general construction, while Z type offers higher bending strength for large-scale projects.
Q: Can you provide coating for marine environments?
A: Yes, we offer 3PE, epoxy coating, and galvanizing for corrosion protection.
Send your requirements:
Type (U / Z)
Size
Quantity
Destination port
Reply within 12 hours
ROYAL GROUP
Address
Kangsheng development industry zone,
Wuqing district, Tianjin city, China.
