U-Type Sheet Pile 600x450x10mm | Q355B Steel, EN10249 | Royal Steel Group
| Parameter | Specification |
| Type | U‑Type (Larssen‑style) Sheet Pile |
| Equivalent Model | SLU 18‑7 (or equivalent) |
| Width | 600 mm |
| Height | 450 mm |
| Thickness | 10 mm |
| Unit Weight | ~85.5 kg/m |
| Material | Q355B Low‑Alloy High‑Strength Structural Steel |
| Manufacturing Standard | EN10249 (Cold‑formed steel sheet piles) |
| Length | Customizable (typical range: 6 m – 30 m) |
Q355B belongs to China’s low-alloy high-strength structural steel series. It strikes a great balance between tensile strength, welding performance and bending workability. In terms of mechanical performance, it can be matched with ASTM A572 Grade 50 and European EN S355JR steel grades.
| Property | Value |
| Yield Strength (≤16mm thickness) | ≥ 355 MPa |
| Tensile Strength | 470 – 630 MPa |
| Elongation | ≥ 22% |
| Impact Test Temperature | 0°C |
| Impact Value (Akv) | ≥ 34 J/cm² |
| Advantage | Description |
| Symmetric Cross‑Section | Ensures balanced mechanical performance and ease of handling |
| Superior Drivability | Convenient piling with straightforward alignment |
| High Strength‑to‑Weight Ratio | Q355B material delivers excellent load‑bearing capacity |
| Reliable Interlocking | Precision‑engineered locks create continuous, watertight walls |
| Reusable | Symmetric design facilitates multiple reuse cycles |
| Corrosion Resistant | Suitable for both temporary and permanent marine environments |
| Customizable Lengths | Available in various lengths to match project requirements |
High strength for deep foundation projects
Excellent interlock system for water tightness
Suitable for temporary and permanent structures
Reusable, reducing overall project cost
Available in hot rolled and cold formed types
Hot Rolled Sheet Piles - u type steel sheet piles
| Type | Width (mm) | Height (mm) | Thickness (mm) | Section Area (cm²/m) | Weight (kg/m) | Moment of Inertia (cm⁴/m) |
| U400 | 400 | 125–130 | 8–12 | 75–110 | 58–86 | 1,500–2,800 |
| U500 | 500 | 130–135 | 8–13 | 90–130 | 70–102 | 2,500–4,500 |
| U600 | 600 | 140–150 | 9–14 | 110–160 | 85–125 | 4,000–7,500 |
| U700 | 700 | 150–160 | 10–15 | 130–190 | 100–145 | 6,500–11,000 |
| U750 | 750 | 155–165 | 10–16 | 140–210 | 110–160 | 8,000–13,500 |
Click the button on the right to contact us
Typical Usage Scenarios for Steel Sheet Piles
Earth-retaining wall structures for land development
Watertight cofferdam building for foundation excavation
Harbour, dock and all types of coastal marine works
Flood defence works & river embankment stabilization projects
Underground basement and underground car park construction
Note:
1.Free sampling, 100% after-sales quality assurance, Support any payment method;
2.All other specifications of round carbon steel pipes are available according to your requirement (OEM&ODM)! Factory price you will get from ROYAL GROUP.
Packing Standard
We bind U-shaped sheet piles into uniform bundles using robust steel strapping. Every bundle is fixed with anti-slip steel fasteners to avoid shifting during transit.
For edge protection, hard plastic guards are fitted on both ends of each pile to prevent scratches, deformation and coating damage.
If clients require extra anti-rust treatment, we apply waterproof wrapping film over each finished bundle, suitable for long-distance sea freight to coastal areas.
Transportation Arrangement
We deliver goods via bulk cargo vessels or standard full-container loads based on order tonnage.
Our team optimizes stacking layout inside containers and holds to maximize loading capacity while ensuring structural safety.
Complete loading photos, weight slips and packing lists will be provided before shipment for customs clearance at destination ports.
Transportation: Express (Sample Delivery), Air, Rail, Land, Sea shipping (FCL or LCL or Bulk)
Q1: Could you briefly introduce Royal Steel Group?
A1: Established back in 2012, Royal Steel Group is a professional high-tech manufacturer and exporter of structural steel goods, with its base located in Tianjin, China. Our products are shipped to more than 160 nations globally, and we’ve set up local branch offices in the United States, Guatemala and Mexico to support regional clients.
Q2: Could you share the detailed specs and applicable standards for these sheet piles?
A2: The item here is U-type Larssen steel sheet pile, produced from high-strength Q355B steel material and compliant with EN10249 norm. Its dimension measures 600mm width × 450mm depth × 10mm wall thickness, with a linear weight of roughly 85.5 kg/m, matching the model SLU 18-7.
Q3: Does Royal Steel follow international quality norms during production?
A3: Absolutely. Our steel products fully conform to mainstream global specifications such as ASTM, EN, JIS and Chinese GB standards. We run 15 fully automated production lines, carrying out rigorous inspection procedures covering every stage, from incoming raw steel to finished sheet piles.
Q4: What construction projects commonly use this U-type sheet pile?
A4: This U profile sheet pile fits a wide range of civil and marine works: deep foundation reinforcement, retaining wall structures, watertight cofferdams, dock & port infrastructure, river flood prevention, as well as both temporary and long-term soil retaining engineering.
Q5: How do I request pricing details or extra technical data?
A5: You may browse our official portal www.royalsteelgroup.com, or reach out to our regional sales staff via our branches in US, Guatemala and Mexico to receive fast, dedicated support.
