API 5L Steel Pipe Supplier | Seamless & Welded Line Pipe Manufacturer
| API 5L Steel Pipe Product Detail | |
| Grades | API 5L Grade B, X42, X52, X56, X60, X65, X70, X80 |
| Specification Level | PSL1, PSL2 |
| Outer Diameter Range | 1/2” to 2”, 3”, 4”, 6”, 8”, 10”, 12”, 16 inches, 18 inches, 20 inches, 24 inches up to 40 inches. |
| Thickness Schedule | SCH 10. SCH 20, SCH 40, SCH STD, SCH 80, SCH XS, to SCH 160 |
| Manufacturing Types | Seamless, Welded ERW, SAW in LSAW, DSAW, SSAW, HSAW |
| Ends Type | Beveled ends, Plain ends |
| Length Range | SRL , DRL , 20 FT (6 meters), 40FT (12 meters) or, customized |
| Protection Caps | plastic or iron |
| Surface Treatment | Natural, Varnished, Black Painting, FBE, 3PE (3LPE), 3PP, CWC (Concrete Weight Coated) CRA Clad or Lined |
Wide range of grades from Grade B to X80
Suitable for high-pressure pipeline systems
Strict quality control with full traceability
Multiple coating options for long service life
API 5L Steel Pipe Size Chart
| Outside Diameter (OD) | Wall Thickness (WT) | Nominal Pipe Size (NPS) | Length | Steel Grade Available | Type |
| 21.3 mm (0.84 in) | 2.77 – 3.73 mm | ½″ | 5.8 m / 6 m / 12 m | Grade B – X56 | Seamless / ERW |
| 33.4 mm (1.315 in) | 2.77 – 4.55 mm | 1″ | 5.8 m / 6 m / 12 m | Grade B – X56 | Seamless / ERW |
| 60.3 mm (2.375 in) | 3.91 – 7.11 mm | 2″ | 5.8 m / 6 m / 12 m | Grade B – X60 | Seamless / ERW |
| 88.9 mm (3.5 in) | 4.78 – 9.27 mm | 3″ | 5.8 m / 6 m / 12 m | Grade B – X60 | Seamless / ERW |
| 114.3 mm (4.5 in) | 5.21 – 11.13 mm | 4″ | 6 m / 12 m / 18 m | Grade B – X65 | Seamless / ERW / SAW |
| 168.3 mm (6.625 in) | 5.56 – 14.27 mm | 6″ | 6 m / 12 m / 18 m | Grade B – X70 | Seamless / ERW / SAW |
| 219.1 mm (8.625 in) | 6.35 – 15.09 mm | 8″ | 6 m / 12 m / 18 m | X42 – X70 | ERW / SAW |
| 273.1 mm (10.75 in) | 6.35 – 19.05 mm | 10″ | 6 m / 12 m / 18 m | X42 – X70 | SAW |
| 323.9 mm (12.75 in) | 6.35 – 19.05 mm | 12″ | 6 m / 12 m / 18 m | X52 – X80 | SAW |
| 406.4 mm (16 in) | 7.92 – 22.23 mm | 16″ | 6 m / 12 m / 18 m | X56 – X80 | SAW |
| 508.0 mm (20 in) | 7.92 – 25.4 mm | 20″ | 6 m / 12 m / 18 m | X60 – X80 | SAW |
| 610.0 mm (24 in) | 9.53 – 25.4 mm | 24″ | 6 m / 12 m / 18 m | X60 – X80 | SAW |
Click the Button on The Right
PSL 1 (Product Specification Level 1) : For pipelines built to a basic standard quality level.
PSL 2 (Product Specification Level 2) : Using higher mechanical properties, tighter chemical controls and NDT, more aggressive specification.
| Item | PSL1 | PSL2 | Notes |
| Chemical Composition Control | Standard limits on C, Mn, P, S | Stricter limits, lower P and S; additional microalloy element control allowed | PSL2 is more suitable for low-temperature and corrosive environments |
| Yield Strength (MPa) | According to grade specification | Same as PSL1; slightly higher for some high-grade steels | Basic mechanical requirements are similar |
| Tensile Strength (MPa) | According to grade specification | Same as PSL1 | |
| Elongation (%) | According to grade specification | Same as PSL1 | |
| Low-Temperature Impact (Charpy V-Notch) | Optional or per end-use requirement | Mandatory; typically tested at -20°C or -50°C | Enhances toughness at low temperature |
| Weldability | Meets standard requirements | Stricter, weldability tests often required | PSL2 demands higher weld performance |
| Dimensional Tolerance | Standard range | Stricter | PSL2 has tighter control on diameter and wall thickness |
| Defect Control / NDT | Standard inspection; UT/RT optional | Mandatory UT/RT/MPI | Ensures higher pipeline safety |
| Application Environment | General pipeline transportation | High-pressure, low-temperature, corrosive pipelines | PSL2 is preferred for projects with high safety requirements |
| Cost | Relatively lower | Slightly higher | Due to stricter inspection and manufacturing requirements |
Long-distance oil & gas transmission pipelines: Made with high pressure resistance and reliable sealing performance to ensure safe, efficient cross-regional energy delivery.
Municipal natural gas distribution networks: Durable and stable in operation, providing consistent natural gas supply for residential and commercial use.
Water pipeline systems: Featuring excellent corrosion resistance, ideal for urban drinking water supply, industrial water transmission and sewage treatment projects.
Industrial and energy infrastructure: Strong structural stability and long service life, widely used in power plants, petrochemical bases, energy facilities and other heavy-duty construction projects.
PSL2 has stricter requirements in:
Chemical composition
Mechanical properties
Impact testing
Non-destructive testing (NDT)
Q: What is the difference between seamless and welded pipe?
A: Seamless pipes are stronger for high pressure, while welded pipes are more cost-effective for large diameter.
Q: Do you provide third-party inspection?
A: Yes, SGS / BV inspection is available before shipment.
