ASTM A36 Hot Rolled Carbon Steel Sheet S275jr Mild Steel Carbon Plate

Short Description:

Hot rolled steel sheet is a steel product made by rolling steel billets under high temperature conditions. It has good plasticity, toughness and processing performance, and the surface is usually covered with oxide scale. It has a wide range of size specifications.


  • Processing Services: Bending, Decoiling, Cutting, Punching
  • Inspection: SGS, TUV, BV, factory inspection
  • Standard: AiSi, ASTM, DIN, GB, JIS
  • Width: customize
  • Application: building materials
  • Certificate: JIS, ISO9001, BV BIS ISO
  • Delivery Time: 3-15 days (according to the actual tonnage)
  • Port Information: Tianjin Port, Shanghai Port, Qingdao Port, etc.
  • Product Detail

    Product Tags

    STEEL PLATE

    Product Detail

    Item Description
    Product Name Hot Rolled Steel Sheet / Plate
    Standard ASTM / EN / JIS (as required)
    Material Grade A36, S235JR, S275JR, S355JR or equivalent
    Production Process Hot rolled
    Thickness 2 mm – 300 mm
    Width 1000 mm – 3000 mm
    Length 2000 mm – 12000 mm or customized
    Surface Condition Black / Pickled / Oiled
    Edge Condition Mill edge / Cut edge / Slit edge
    Tolerance As per international standards
    Processing Services Cutting, shearing, drilling, bending, welding available
    Inspection Mill Test Certificate (MTC); third-party inspection available upon request
    Packaging Seaworthy export packing with steel straps and waterproof protection
    Delivery Terms FOB / CFR / CIF
    Loading Port Tianjin, Qingdao, Shanghai, and other major Chinese ports



    Steel Plate Gauge Table



    Gauge Thickness Comparison Table
    Gauge Mild Aluminum Galvanized Stainless
    Gauge 3 6.08mm 5.83mm 6.35mm
    Gauge 4 5.7mm 5.19mm 5.95mm
    Gauge 5 5.32mm 4.62mm 5.55mm
    Gauge 6 4.94mm 4.11mm 5.16mm
    Gauge 7 4.56mm 3.67mm 4.76mm
    Gauge 8 4.18mm 3.26mm 4.27mm 4.19mm
    Gauge 9 3.8mm 2.91mm 3.89mm 3.97mm
    Gauge 10 3.42mm 2.59mm 3.51mm 3.57mm
    Gauge 11 3.04mm 2.3mm 3.13mm 3.18mm
    Gauge 12 2.66mm 2.05mm 2.75mm 2.78mm
    Gauge 13 2.28mm 1.83mm 2.37mm 2.38mm
    Gauge 14 1.9mm 1.63mm 1.99mm 1.98mm
    Gauge 15 1.71mm 1.45mm 1.8mm 1.78mm
    Gauge 16 1.52mm 1.29mm 1.61mm 1.59mm
    Gauge 17 1.36mm 1.15mm 1.46mm 1.43mm
    Gauge 18 1.21mm 1.02mm 1.31mm 1.27mm
    Gauge 19 1.06mm 0.91mm 1.16mm 1.11mm
    Gauge 20 0.91mm 0.81mm 1.00mm 0.95mm
    Gauge 21 0.83mm 0.72mm 0.93mm 0.87mm
    Gauge 22 0.76mm 0.64mm 085mm 0.79mm
    Gauge 23 0.68mm 0.57mm 0.78mm 1.48mm
    Gauge 24 0.6mm 0.51mm 0.70mm 0.64mm
    Gauge 25 0.53mm 0.45mm 0.63mm 0.56mm
    Gauge 26 0.46mm 0.4mm 0.69mm 0.47mm
    Gauge 27 0.41mm 0.36mm 0.51mm 0.44mm
    Gauge 28 0.38mm 0.32mm 0.47mm 0.40mm
    Gauge 29 0.34mm 0.29mm 0.44mm 0.36mm
    Gauge 30 0.30mm 0.25mm 0.40mm 0.32mm
    Gauge 31 0.26mm 0.23mm 0.36mm 0.28mm
    Gauge 32 0.24mm 0.20mm 0.34mm 0.26mm
    Gauge 33 0.22mm 0.18mm 0.24mm
    Gauge 34 0.20mm 0.16mm 0.22mm
    热轧板_01
    热轧板_02
    热轧板_03
    热轧板_04

    Product Of Advantages

    The main features of  include:

    High strength & high reliability: It’s stable mechanical property could apply in structural.It is easy to cut, bend, drill and work, for all kinds of fabrication.

    Good Weldability: It can be welded by the majority of welding processes, making t\he production and building process easier.

    Range of Specs: It is available in different thicknesses, widths and lengths to meet your project requirements.

    Budget-friendly option: Provides good performance to price ratio for high volume projects.

    Main Application

    application

    1.Fluid / Gas delivery, Steel structure, Construction;
    2.ROYAL GROUP ERW/Welded round carbon steel pipes, which with Highest quality and strong supply ability are widely used in Steel structure and Construction.

    Note:
    1.Free sampling, 100% after-sales quality assurance, Support any payment method;
    2.All other specifications of round carbon steel pipes are available according to your requirement (OEM&ODM)! Factory price you will get from ROYAL GROUP.

    Process of production

    Hot rolling is a mill process which involves rolling the steel at a  high temperature

    which is above the steel’s recrystallization temperature.

    热轧板_08

    Product Inspection

    sheet  (1)
    sheet  (209)
    QQ图片20210325164102
    QQ图片20210325164050

    Packing and Transportation

    Packaging is generally naked, steel wire binding, very strong.
    If you have special requirements, you can use rust proof packaging, and more beautiful.

    Steel plate weight limit
    Due to the high density and weight of steel plates, appropriate vehicle models and loading methods need to be selected according to specific conditions during transportation. Under normal circumstances, steel plates will be transported by heavy trucks. Transport vehicles and accessories must comply with national safety standards, and relevant transport qualification certificates must be obtained.
    2. Packaging requirements
    For steel plates, packaging is very important. During the packaging process, the surface of the steel plate must be carefully inspected for slight damage. If there is any damage, it should be repaired and reinforced. In addition, in order to ensure the overall quality and appearance of the product, it is recommended to use professional steel plate covers for packaging to prevent wear and moisture caused by transportation.
    3. Route selection
    Route selection is a very important issue. When transporting steel plates, you should choose a safe, calm and smooth route as much as possible. You should try your best to avoid dangerous road sections such as side roads and mountain roads to avoid losing control of the truck and overturning and causing serious damage to the cargo.
    4. Arrange time reasonably
    When transporting steel plates, time should be reasonably arranged and sufficient time reserved to deal with various situations that may arise. Whenever possible, transportation should be carried out during off-peak periods to ensure transportation efficiency and minimize traffic pressure.
    5. Pay attention to safety and security
    When transporting steel plates, attention should be paid to safety issues, such as using seat belts, checking vehicle conditions in a timely manner, keeping road conditions clear, and providing timely warnings on dangerous road sections.
    In summary, there are many things that need to be paid attention to when transporting steel plates. Comprehensive considerations must be made from steel plate weight restrictions, packaging requirements, route selection, time arrangements, safety guarantees and other aspects to ensure that cargo safety and transportation efficiency are maximized during the transportation process. Best condition.

    热轧板_05
    STEEL PLATE (2)

    Transportation: Express (Sample Delivery), Air, Rail, Land, Sea shipping (FCL or LCL or Bulk)

    热轧板_07

    Our Customer

    Entertaining customer

    We receive Chinese agents from customers all over the world to visit our company, every customer is full of confidence and trust in our enterprise.

    {E88B69E7-6E71-6765-8F00-60443184EBA6}
    QQ图片20230105171510
    QQ图片20230105171554
    QQ图片20230105171656
    QQ图片20230105171539

    FAQ

    1. What is hot rolled steel sheet?

    Hot rolled steel sheet is produced by rolling steel at high temperatures, resulting in a material with good strength, toughness, and excellent formability.

    2. What are the typical applications?

    It is widely used in construction, machinery manufacturing, shipbuilding, bridge projects, automotive parts, and pressure vessels.

    3. Can you provide custom sizes?

    Yes, we offer customized thickness, width, and length according to customer requirements, along with cutting and processing services.

    4. What is your minimum order quantity (MOQ)?

    MOQ is flexible and depends on product specifications. Both small and bulk orders are supported.

    5. What is the delivery time?

    Typical delivery time is 7–25 days depending on order quantity and processing requirements
