Royal Steel Group offers high-quality steel sheet piles, including U-type steel sheet piles and Z-type steel sheet piles, widely used in civil engineering and marine construction. Our steel sheet piles are made from S235JR, S355JR, ASTM A572, JIS A5528, ensuring high strength, durability, and corrosion resistance.
We export sheet piles and related products and can tailor solutions to your project needs in various countries, including Indonesia, the Philippines, Malaysia, and Mexico.
U-Type Steel Sheet Pile Specifications
| Designation | Height (m) | Width (mm) | Web Thickness (mm) | Sectional Area (cm²/m) | Weight (kg/m) | Moment of Inertia Ix (cm⁴/m) | Section Modulus Wx (cm³/m) |
| U-200 | 3–12 | 200 | 6–12 | 48–75 | 38–60 | 1800–3200 | 180–320 |
| U-250 | 3–15 | 250 | 6–14 | 60–95 | 45–75 | 2500–4500 | 200–400 |
| U-300 | 3–18 | 300 | 8–16 | 85–130 | 65–100 | 4000–7200 | 250–500 |
| U-350 | 3–18 | 350 | 10–18 | 120–180 | 90–140 | 6500–11000 | 350–650 |
Z-Type Steel Sheet Pile Specifications
| Designation | Height (m) | Width (mm) | Web Thickness (mm) | Sectional Area (cm²/m) | Weight (kg/m) | Moment of Inertia Ix (cm⁴/m) | Section Modulus Wx (cm³/m) |
| Z-250 | 3–12 | 250 | 6–12 | 55–85 | 42–65 | 2000–3500 | 190–340 |
| Z-300 | 3–15 | 300 | 8–14 | 80–115 | 60–95 | 3500–6500 | 240–480 |
| Z-350 | 3–18 | 350 | 10–16 | 110–160 | 85–135 | 6000–10000 | 330–600 |
| Z-400 | 3–18 | 400 | 12–18 | 150–210 | 115–170 | 9000–15000 | 450–750 |
